Software Verification Examples for SCADA Pro
27
Table A3.2.1. Comparison of Results for Displacements.
Vertical Displacement
(mm)
ScadaPro
Sap2000
Abaqus
max values
1.62
1.78
1.80
ScadaPro
Sap2000
Abaqus
Figure A3.2.2. Bending Moment Mxx (kNm/m) according to ScadaPro, Sap2000 and
Abaqus Analysis.
