Software Verification Examples for SCADA Pro
25
Table A3.1.2. Comparison of Results for Bending Moments (Load Case 1).
Bending Moment
ScadaPro
Sap2000
Abaqus
Exact Solution
Mxx (kNm/m) at
center of plate
(=Myy)
3.65
3.67
3.69
4.04
max value of Mxy
(kNm/m)
1.69
1.72
1.63
-
Computer Files
The project files for this example are “FF6_Fix”, “FF6_SS” & “FF6_EF”. These files are
provided as part of the ScadaPro installation.
Conclusion
The result comparison reflects acceptable agreement between ScadaPro software and results
obtained from Sap2000 and Abaqus.
