Software Verification Examples for SCADA Pro
17
Horizontal members under vertical loading
Fixed boundary conditions
Two different materials
Results Comparison
Vertical displacements and bending moments along horizontal principal axis obtained from
ScadaPro analysis are presented in Table A2.4.4 and Table A2.4.5 respectively and
compared with those obtained from Sap2000 and Abaqus software.
Table A2.4.4. Comparison of Results for Vertical Displacements.
Vertical
Displacements (mm)
at
ScadaPro
Sap2000
Abaqus
nodes K1, K2, K3, K4
7.02
7.02
7.16
Table A2.4.5. Comparison of Results for Bending Moments.
Bending Moment
(kNm) at
ScadaPro
Sap2000
Abaqus
ends of steel beams
forming square shape
(Group A)
80.87/19.97
80.69/19.97
80.91/20.25
ends of steel beams
outside square shape
(Group B)
123.52/0.04
123.53//0.04
123.25/0.04
ends of columns (C1,
C2, C3)
C1:108.12/53.18
C2:0.00/0.00
C3:72.30/36.16
C1:108.12/53.18
C2:0.00/0.00
C3:72.30/36.16
107.83/52.92
0.00/0.00
72.23/35.83
Computer Files
The project file for this example is “FF4”. These files are provided as part of the ScadaPro
installation.
Conclusion
The result comparison reflects acceptable agreement between the ScadaPro software and
results obtained from Sap2000 and Abaqus.
