Software Verification Examples for SCADA Pro

14

Results Comparison

Vertical Displacements and Bending Moments along principal axis of cross section, for

each load case, obtained from ScadaPro analysis, are presented in Table A2.3.1 and A2.3.2

respectively as compared with those obtained from Sap2000 and Abaqus software.

Table A2.3.1. Comparison of Results for Vertical Displacements of Frame I & III.

Vertical Displacement

(mm) at

ScadaPro

Sap2000

Abaqus

highest point of inclined

beam (node E)

3.27

3.28

3.34

Table A2.3.2. Comparison of Results for Bending Moments of Frame I & III.

Bending Moment

(kNm) at

ScadaPro

Sap2000

Abaqus

highest point of

inlined beams

(node E)

13.46

13.46

13.56

ends of inclined

beams (nodes B, C)

26.88

26.88

26.77

base of columns

(nodes A, D)

1.42

1.42

1.40

Computer Files

The project file for this example is “FF3”. These files are provided as part of the ScadaPro

installation.

Conclusion

The result comparison reflects acceptable agreement between ScadaPro software and results

obtained from Sap2000 and Abaqus.
