Software Verification Examples for SCADA Pro
43
ScadaPro
Sofistik
Cedrus-5
Figure B2.1.3. Bottom transverse reinforcement Xk (cm
2
/m) for Support Case Sup2
according to ScadaPro, Sofistik and Cedrus-5 software (Comb2).
Table B2.1.1. Comparison of Results for Vertical Displacements (Comb1).
Vertical
Displacement (mm)
at
ScadaPro
Sofistik
Cedrus-5
center
point of plate
(Support Case 1)
3.91
3.80
3.92
center
point of plate
(Support Case 2)
3.12
3.04
3.13
