Software Verification Examples for SCADA Pro
61
Assumptions
During analysis, shear deformations are neglected. Section properties are automatically
recovered from the cross section library of ScadaPro.
Technical Features in ScadaPro Tested
Three – dimensional analysis of beam elements
Results Comparison
Maximum values of vertical displacements (Comb1) and axial forces (Comb2) along
principal axis of cross section obtained from ScadaPro analysis, are presented in Tables
B3.1.1 & B3.1.2 respectively and compared with those obtained from Statik-5 software.
Table B3.1.1. Comparison of Results for vertical Displacements (Comb1)
Vertical Displacements
DY(mm) at
ScadaPro
Statik-5
Node ‘N1’
5.49
5.61
Node ‘N2’
4.80
4.92
Table B3.1.2. Comparison of Results for Αxial forces (Comb2)
Αxial Forces
N(kN) at
ScadaPro
Statik-5
Element ‘E1’
50.48
52.07
Element ‘E2’
118.84
120.84
Element ‘E3’
106.56
109.00
Computer Files
The project file for this example is “B5”. These files are provided as part of the ScadaPro
installation.
Conclusion
The result comparison reflects acceptable agreement between ScadaPro software and results
obtained from Statik-5.
